4-20 “Job Done” Examples - (Example 2) Date Code 20010518
SEL-2020 Instruction Manual
! Use the \<ENTER> special character sequence at the end of a line to continue on a
second line.
2. Use the SET P command to configure Port 9 as a printer port.
*>>SET P 9<ENTER>
SET P 9<ENTER>SET P 9<ENTER>
SET P 9<ENTER>
Port communications settings for Port 9
Device Type (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) DEVICE = P ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Identification String
PORTID =""
? Line Printer<ENTER>
Line Printer<ENTER>Line Printer<ENTER>
Line Printer<ENTER>
Communications Settings
Baud Rate (300, 600, 1200, 2400, 4800, 9600,
19200) BAUD = 9600 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Number data bits (7,8) DATABIT = 8 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Stop Bits (1,2) STOPBIT = 2 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Parity (N,O,E,1,0) PARITY = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Enable RTS/CTS handshaking (Y/N) RTS_CTS = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Enable XON/XOFF flow control (Y/N) XON_XOFF= Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Timeout in minutes (0.0-30.0) TIMEOUT = OFF ? 30 <ENTE
30 <ENTE30 <ENTE
30 <ENTER>
R>R>
R>
PORT:9
DEVICE = P
PORTID ="Line Printer"
BAUD = 9600
DATABIT = 8 STOPBIT = 2 PARITY = N
RTS_CTS = N XON_XOFF= Y
TIMEOUT = 30.0
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 9 Settings Changed
*>>
Notes:

Enter P to identify the device type as a printer.
Enter an identification for the SEL-2020 port directory.
!
Enter communication parameters compatible with the printer.

!
