Date Code 20010518 “Job Done” Examples - (Example 2) 4-23
SEL-2020 Instruction Manual
result in output on any of these types of printers. The <CTRL-L> is the form feed from
most keyboards.
3. Use the TOGGLE command to issue the time and date command stored in MESG1 on Port 7
to the relay on Port 7.
*>>TOGGLE 7:D1<ENTER>
TOGGLE 7:D1<ENTER>TOGGLE 7:D1<ENTER>
TOGGLE 7:D1<ENTER>
Bit Toggled
*>>
Note the time you toggled the bit. Enter transparent communication with the relay on Port 7 and
check the time on the relay. The relay time should be 01:00:00 plus the number of seconds since
you toggled the message trigger bit. This synchronization technique is not as accurate as with
IRIG-B. You can expect the time on the relay to be synchronized within three seconds of the
SEL-2020 clock.
