4-22 “Job Done” Examples - (Example 2) Date Code 20010518
SEL-2020 Instruction Manual
VERIFY AND TEST ALL COMMUNICATION PATHS
1. Issue the STATUS command to check that IRIG-B signal is present and devices are
connected to ports as expected. This command was used in Example 1. You can also use the
WHO command to see a list of all devices connected to SEL-2020 ports. The SEL-2020
response to the WHO command should look similar to the following screen image:
*>>WHO<ENTER>
WHO<ENTER>WHO<ENTER>
WHO<ENTER>
Date: 03/03/95 Time: 14:21:05
FID=SEL-2020-R115-V0-D961020
Port # Device Protocol Parameters Identification
1 SEL-151 SEL 9600,8,2,N Example 21.6 kV Line - S/N 93245011
2 SEL-151 SEL 9600,8,2,N Example 21.6 kV feeder - S/N 94292025
3 SEL-151 SEL 9600,8,2,N Example 21.6 kV Feeder - S/N 94265010
4 SEL-151 SEL 9600,8,2,N Example 21.6 kV Feeder - S/N 94266022
5 SEL-151 SEL 9600,8,2,N Example 21.6 kV feeder - S/N 95010024
6 SEL-151 SEL 9600,8,2,N Example 21.6 kV feeder - S/N 95011020
7 SEL-151 SEL 9600,8,2,N Example 21.6 kV Feeder. -S/N 95011596
8 Master SEL 38400,8,2,N MODEM
9 Printer Ascii 9600,8,2,N Line Printer
10 SEL IED SEL 9600,8,2,N
11 SEL IED SEL 9600,8,2,N
12 SEL IED SEL 9600,8,2,N
13 SEL IED SEL 9600,8,2,N
14 SEL IED SEL 9600,8,2,N
15 SEL IED SEL 9600,8,2,N
16 SEL IED SEL 9600,8,2,N
F* Master SEL 2400,8,2,N Service port
*>>
2. Once you have established the port settings for the printer, test the connection by using the
PORT command and issuing a message as follows:
*>>PORT 9 E<ENTER>
PORT 9 E<ENTER>PORT 9 E<ENTER>
PORT 9 E<ENTER>
Transparent Communications to Port 9 established
This is a test <ENTER>
This is a test <ENTER>This is a test <ENTER>
This is a test <ENTER>
This is the second line.<ENTER>
This is the second line.<ENTER>This is the second line.<ENTER>
This is the second line.<ENTER>
<CTRL
<CTRL<CTRL
<CTRL-
--
-L><CTRL
L><CTRLL><CTRL
L><CTRL-
--
-D>
D>D>
D>
Transparent Communications to Port 9 terminated
*>>
This example prints the following two lines of text on the printer and then form feeds the
printer.
This is a test.
This is the second line.
Some printers print as they receive each character, some print only when they receive a
complete line, and some do not print until they receive an entire page. This example should
