SET THE SEL-2020, STEP-BY-STEP
For the printer on Port 9, use SET A 9 to output the long event report.
You should see the following screen:
*>>SET A 9<ENTER>
SET A 9<ENTER>SET A 9<ENTER>
SET A 9<ENTER>
Automatic message settings for Port 9
Port Start-Up String
STARTUP =""
? <ENTER>
<ENTER><ENTER>
<ENTER>
Auto Message Settings
How many auto-message sequences (0-12) MSG_CNT = 1 ? 2<ENTER>
2<ENTER> 2<ENTER>
2<ENTER>
Print all buffered unsolicited messages (Y/N) PRINT_ALL= Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Clear unsolicited message buffer after print (Y/N)CLEAR_BUF= Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Item 2 trigger D2
ISSUE2 =NA
? !1:ARCH3<ENTER>
!1:ARCH3<ENTER>!1:ARCH3<ENTER>
!1:ARCH3<ENTER>
Item 2 message
MESG2 =""
? \
\\
\F1:A3;C/<ENTER>
F1:A3;C/<ENTER>F1:A3;C/<ENTER>
F1:A3;C/<ENTER>
Size of user-defined data space in registers USER = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
STARTUP =""
MSG_CNT = 2
PRINT_ALL= Y
CLEAR_BUF= Y
ISSUE2 =!1:ARCH3
MESG2 ="\F01:A3;C/"
USER = 0
Save changes (Y/N) ? Y<
Y<Y<
Y<ENTER>
ENTER>ENTER>
ENTER>
Port 9 Settings Changed
*>>
Notes:  Set MESG_CNT=2 to add a new message trigger and message on Port 9.
Set ISSUE2=!1:ARCH3 to trigger MESG2 when the A3 data region bit, ARCH3, on Port 1
deasserts at the conclusion of a long event report storage sequence.
! Set MESG2=\F1:A3;C/ to send the formatted output from the Port 1, A3 data region to the
printer. When this transfer is complete, clear the Port 1, A3 data region. Depending on
your printer, you may want to issue a form feed after the printing process is completed.
You can do this simply by adding the ASCII form feed character sequence (\00C) to the
end of the MESG2 message string.

!
