4-62 “Job Done” Examples - (Example 8) Date Code 20010518
SEL-2020 Instruction Manual
DEFINING THE SOLUTION
Set the SEL-2020
1. Use SET P 12 to configure Port 12 as an “Other IED” port with the DGH 1000
communication parameters. Use the SET A 12 command to make the following settings:
• Set AUTOBUF=N so Port 12 does not store unsolicited messages.
• Define message trigger ISSUE1 to send a message every 30 seconds.
• Create a message, $1RD\00D, that is sent to the DGH 1000 when triggered.
• Set PARSE and NUM to accept one floating-point number.
Test the Operation
1. Use the TOGGLE command to force data collection and the VIEW command to view the
collected data.
