Schweitzer Engineering Laboratories SEL-2020 - Page 145

Date Code 20010518 “Job Done” Examples - (Example 8) 4-63
SEL-2020 Instruction Manual
SET THE SEL-2020, STEP-BY-STEP
1. Use SET P 12 to configure Port 12 as an “Other IED” port with the DGH 1000
communication parameters.
You should have the following screen:
*>>SET P 12<ENTER>
*>>SET P 12<ENTER>*>>SET P 12<ENTER>
*>>SET P 12<ENTER>
Port communications settings for Port 12
Device Type (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) DEVICE = S ? O<ENTER>
O<ENTER>O<ENTER>
O<ENTER>
Modem Settings
Modem Control (Y/N) MODEM = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Attempt to detect port baud rate (Y/N) AUTO_BAUD= N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Communications Type (A=ASCII, B=Binary) PROTOCOL= INVALID ? A<ENTER>
A<ENTER>A<ENTER>
A<ENTER>
Port Identification String
PORTID =""
? DGH1000<ENTER>
DGH1000<ENTER>DGH1000<ENTER>
DGH1000<ENTER>
Communications Settings
Baud Rate (300, 600, 1200, 2400, 4800, 9600,
19200) BAUD = 9600 ? 300<ENTER>
300<ENTER>300<ENTER>
300<ENTER>
Number data bits (7,8) DATABIT = 8 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Stop Bits (1,2) STOPBIT = 2 ? 1<ENTER>
1<ENTER>1<ENTER>
1<ENTER>
Parity (N,O,E,1,0) PARITY = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Enable RTS/CTS handshaking (Y/N) RTS_CTS = N ? <ENTER>
? <ENTER>? <ENTER>
? <ENTER>
Enable XON/XOFF flow control (Y/N) XON_XOFF= Y ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Port Timeout in minutes (0.0-30.0) TIMEOUT = OFF ? <ENTER>
<ENTER><ENTER>
<ENTER>
PORT:12
DEVICE = O
MODEM = N
AUTO_BAUD= N
PROTOCOL= A
PORTID ="DGH1000"
BAUD = 300
DATABIT = 8 STOPBIT = 1 PARITY = N
RTS_CTS = N XON_XOFF= N
TIMEOUT = OFF
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 12 Settings Changed
*>>
Notes:  Set DEVICE=O to reconfigure the port device type as “Other IED”.
Set PROTOCOL=A to allow ASCII and binary communications.
! Enter the name of the device for port identification.
" Enter communication parameters compatible with the DGH 1000.
!

"
