4-64 “Job Done” Examples - (Example 8) Date Code 20010518
SEL-2020 Instruction Manual
2. Set the SEL-2020 with the SET A 12 command to collect data from the DGH 1000 every 30
seconds.
You should see the following screen:
*>>SET A 12<ENTER>
SET A 12<ENTER>SET A 12<ENTER>
SET A 12<ENTER>
Automatic message settings for Port 12
Save Unsolicited Messages (Y/N) AUTOBUF = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Startup String
STARTUP =""
? <ENTER>
<ENTER> <ENTER>
<ENTER>
Auto-message Settings
How many auto-message sequences (0-12) MSG_CNT = 0 ? 1
11
1<ENTER>
<ENTER><ENTER>
<ENTER>
Item 1 trigger D1
ISSUE1 = NA
? P00:00:30<ENTER>
P00:00:30<ENTER>P00:00:30<ENTER>
P00:00:30<ENTER>
Item 1 message
MESG1 = ""
? $1RD
$1RD$1RD
$1RD\
\\
\00D<ENTER>
00D<ENTER>00D<ENTER>
00D<ENTER>
Item 1 response parsing method (0=IGNORE,
1=ASCII_INT, 2=ASCII_FLOAT, 3=CHAR_STRING, 4=INT_STRING)PARSE1 = 0 ? 2<ENTER>
2<ENTER>2<ENTER>
2<ENTER>
Item 1 number of data items NUM1 = 1 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Time delay to allow response to complete (OFF, ON) DELAY1 = ON ? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive Settings
Enable use of archive data items (Y/N) ARCH_EN = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Size of user-defined data space in registers USER = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
AUTOBUF = N
STARTUP =""
MSG_CNT = 1
ISSUE1 = P00:00:30.0
MESG1 = "$1RD\00D"
PARSE1 = 2
NUM1 = 1
DELAY1 = ON
ARCH_EN = N
USER = 0
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 12 Settings Changed
*>>

!
"
#
$
