SET Function
Port 1 Port 2 . . . Port 16 Port F
Port
Configuration
SET P 1 SET P 2 . . . SET P 16 SET P F
Automatic
Messages
SET A 1 SET A 2 . . . SET A 16 ------
User-Defined
Commands
SET U 1
(not printer
ports)
SET U 2
(not printer
ports)
. . .
SET U 16
(not printer
ports)
------
Data
Movement
Equations
SET M 1 SET M 2 SET M 16
------
Logic
Equations
SET L 1 SET L 2 SET L 16 ------
Global
Settings
SET G
(not port
specific)
Calibration
Settings
SET C
(not port
specific)
Figure 6.1: SET P, SET A, SET U, SET M, SET L, SET G, and SET C as they Apply to
SEL-2020 Ports
