Date Code 20010518 Settings 6-3
SEL-2020 Instruction Manual
Table 6.1: Variations on the SET Command
Command Sets Format Application
SET P n - Port ID.
- All port communication
parameters.
SET P
SET P 1
SET P 2 PARITY
Set current port.
Set Port 1.
Set Port 2 starting at
entry PARITY.
SET A n - Unsolicited message control.
- Automatic messages and
trigger conditions.
- Data parsing.
SET A
SET A 4
SET A 3 ISSUE1A
Set current port.
Set Port 4.
Set Port 3 starting with
ISSUE1A.
SET U n - SEL-2020 command set
control.
- User-defined commands.
SET U
SET U 4
SET U 12 READ
Set current port.
Set Port 4.
Set Port 12 starting
with READ setting.
SET M n - Define data scaling and
movement equations
SET M
SET M 7
Set current port
Set Port 7
SET L n - Logic equations SET L
SET L 6
SET L 12 CBR2
Set current port
Set Port 6
Set Port 12 starting
with CBR2 setting
SET G - SEL-2020 ID.
- Intermediate SEL
OGIC
Control Equation Elements.
- Contact output functions.
SET G
SET G ID
Set global settings.
Set global settings
starting at ID.
SET C - Clock oscillator frequency.
- Settings valid.
SET C Clock calibration,
validate settings after
ROM change.
Note: The SET A, SET M, and SET L commands are not available on Port F. SET A and
SET M are not available if the port device type is set to Unused. The SET U command
is not available on Port F or if the port device type is set to Unused or Printer. You
establish the device type in the port communications settings (SET P).
