6-40 Settings Date Code 20010518
SEL-2020 Instruction Manual
output to be deasserted, its input must be deasserted for the dropout time. If an I/O board is
installed, you may define conditions that assert outputs on the board.
You define the logic elements using SEL
OGIC Control Equations and set their timers using the
SET G command. For a complete discussion of these equations, see Section 7: SEL
OGIC
Control Equations.
Table 6.18 includes a complete description of the SET G settings.
Table 6.18: SET G Global Settings and Definitions
Setting Comment
ID
Prompt. Device Identification.
Description. Any string of up to 40 characters that you wish to use to identify this device.
TIME_SRC
Prompt. SEL-2020 Time Synchronization source (IRIG, DNP, OFF).
Description. Select the source used by the SEL-2020 to time-synchronize itself.
LOG_EN
Prompt. Enable use of intermediate logic (Y/N).
Description. There are five intermediate logic variables, three of which have associated
timers. You set this setting to Y (Yes) to enable their use, or set it to N (No) if you do not
plan to use them.
V
Prompt. V=.
Description. You enter a SEL
OGIC Control Equation definition for the intermediate logic
element V.
W
Prompt. W=.
Description. You enter a SEL
OGIC Control Equation definition for the intermediate logic
element W.
X
Prompt. X=.
Description. You enter a SEL
OGIC Control Equation definition for the intermediate logic
element X.
Y
Prompt. Y=.
Description. You enter a SEL
OGIC Control Equation definition for the intermediate logic
element Y.
Z
Prompt. Z=.
Description. You enter a SEL
OGIC Control Equation definition for the intermediate logic
element Z.
XPICKUP
Prompt. X Timer Pickup time (seconds).
Description. The range is 0.0-86400.0 seconds in 0.1 second increments.
XDROPOUT
Prompt. X Timer Dropout time (seconds).
Description. The range is 0.0-86400.0 seconds in 0.1 second increments.
YPICKUP
Prompt. Y Timer Pickup time (seconds).
Description. The range is 0.0-86400.0 seconds in 0.1 second increments.
YDROPOUT
Prompt. Y Timer Dropout time (seconds).
Description. The range is 0.0-86400.0 seconds in 0.1 second increments.
