6-48 Settings Date Code 20010518
SEL-2020 Instruction Manual
SETTINGS SHEET - MASTER PORT (SEL or LMD protocol) - SET P and SET A
Date
Approved by
SEL-2020 S/N
Port ( )
SET P
DEVICE (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) M
PROTOCOL** (S=SEL, L=LMD, M=Modbus, D=DNP)
ADDRESS* First LMD port address (1-8)
PREFIX* LMD address prefix character (@, #, $, %, &)
SETTLE* LMD port settle time (0-30 seconds)
FAST_OP*** Enable Fast Operate commands (Y/N)
PORTID Port identification string
MODEM Modem control (Automatically Y if modem installed,
automatically N if LMD protocol is selected) (Y/N)
MSTR Startup string (only if MODEM is Y)
CD_CTS Modem CD connected to CTS input (Y/N) (only if MODEM is Y)
BAUD** (300,600,1200,2400,4800,9600,19200, 38400)
DATABIT** Number data bits (7, 8)
STOPBIT** Stop bits (1, 2)
PARITY** (N, O, E, 1, 0)
RTS_CTS Enable RTS_CTS handshaking (Y/N)
XON_XOFF Enable XON_XOFF flow control (Y/N)
TIMEOUT Port timeout (0.0-30.0 minutes)
ECHO** Echo received characters (Y/N)
AUTOHELP Automatic help messages enabled (Y/N)
TERTIME1 First delay time (0-600 seconds)
TERSTRING1 Termination string
TERTIME2 Second delay time (0-600 seconds)
SET A
MSG_CNT How many auto-message sequences (0-12)
ISSUE1-12 Items 1-12 triggers D1-D12 = See Worksheet SET A
MESG1-12 Items 1-12 messages See Worksheet SET A
USER Size of user-defined data space in registers
SET U See Worksheet SET U
* Applies if PROTOCOL set to LMD.
** Port F is limited to baud rates from 300-9600, 8 data bits (including parity), 1 stop bit, SEL protocol, echo
enabled, and parity options N, 0, and E.
*** Applies if Protocol set to SEL.
