Date Code 20010518 Settings 6-49
SEL-2020 Instruction Manual
SETTINGS SHEET - MASTER Modbus PORT - SET P
Date
Approved by
SEL-2020 S/N
Port ( )
SET P
DEVICE (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) M
PROTOCOL (S=SEL, L=LMD, M=Modbus, D=DNP) M
MAP_TYPE (F=Float, I=Integer)
START_ID Starting Code for ID list (0-255)
SETTLE1 Transmission delay from RTS assertion, ms
SETTLE2 Post-transmit RTS deassertion delay, ms
ADDRESS1 Address of Port 1 (1-247)
ADDRESS2 Address of Port 2 (1-247)
ADDRESS3 Address of Port 3 (1-247)
ADDRESS4 Address of Port 4 (1-247)
ADDRESS5 Address of Port 5 (1-247)
ADDRESS6 Address of Port 6 (1-247)
ADDRESS7 Address of Port 7 (1-247)
ADDRESS8 Address of Port 8 (1-247)
ADDRESS9 Address of Port 9 (1-247)
ADDRESS10 Address of Port 10 (1-247)
ADDRESS11 Address of Port 11 (1-247)
ADDRESS12 Address of Port 12 (1-247)
ADDRESS13 Address of Port 13 (1-247)
ADDRESS14 Address of Port 14 (1-247)
ADDRESS15 Address of Port 15 (1-247)
ADDRESS16 Address of Port 16 (1-247)
PORT ID Port identification string
BAUD (300,600,1200,2400,4800,9600,19200,38400)
PARITY (N,O,E)
SET A
MSG_CNT How many auto-message sequences (0-1)
ISSUE1 Item 1 trigger D1=
MESG1 Item 1 message 20USER
ARCH_EN Enable use of archive data items (Y/N)
ISSUE1A Item 1A trigger ARCH1=
MESG1A Item 1A message 20USER
USER Size of user-defined data space in registers
SET U
Not available.
