6-50 Settings Date Code 20010518
SEL-2020 Instruction Manual
SETTINGS SHEET - MASTER DNP PORT - SET P
Date
Approved by
SEL-2020 S/N
Port ( )
SET P
DEVICE (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) M
PROTOCOL (S=SEL, L=LMD, M=Modbus, D=DNP) D
ADDRESS DNP Address (0-65534 or 0000h-FFFEh)
CLASS Class for event data (0 for no event, 1-3)
16BIT Use 16 or 32-bit default variations for analog inputs
SO_TIMEOUT Select/Operate time-out interval, seconds (0.0-30.0)
DL_CONFIRM Number of data-link retries (0 for no confirm, 1-15)
DL_TIMEOUT Data Link Time-out interval, seconds (0.0-30.0)
MIN_DELAY Minimum Delay from DCD to transmission, ms
MAX_DELAY Maximum Delay from DCD to transmission, ms
SETTLE1 Transmission delay from RTS assertion, ms
SETTLE2 Post-transmit RTS deassertion delay, ms
REPORT_ON Percent of Full-Scale Change to Report on (0-100%)
UNSOL_REP Alow Unsolicited Reporting (Y/N)
UNSOL_POW Enable unsolicited messages on power-up (Y/N)
REP_ADDR Address of master to Report to (0-65534 or 0000h-FFFEh)
NUM_EVENT Number of events to transmit on (1-200)
AGE_TX Age of oldest event to force transmit on, sec (1.0-60.0)
CONFIRM_TO Time-out for confirmation of unsolicited message, ms
PORT ID Port identification string
BAUD (300,600,1200,2400,4800,9600,19200,38400)
PARITY (N,O,E)
SET A
MSG_CNT How many auto-message sequences (0-1)
ISSUE1 Item 1 trigger, D1 =
MESG1 Item 1 message 20USER
ARCH_EN Enable use of archive data items (Y/N)
ISSUE1A Item 1A trigger, ARCH1 =
MESG1A Item 1A message 20USER
USER Size of user-defined data space
SET U
