Date Code 20010518 Settings 6-51
SEL-2020 Instruction Manual
SETTINGS SHEET - PRINTER - SET P and SET A
Date
Approved by
SEL-2020 S/N
Port ( )
SET P
DEVICE (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) P
PORTID Port identification string
BAUD (300,600,1200,2400,4800,9600,19200)
DATABIT Number data bits (7, 8)
STOPBIT Stop bits (1, 2)
PARITY (N, O, E, 1, 0)
RTS_CTS Enable RTS_CTS handshaking (Y/N)
XON_XOFF Enable XON_XOFF flow control (Y/N)
TIMEOUT Port timeout (0.0-30.0 minutes)
SET A
STARTUP Port Startup String
MSG_CNT How many auto-message sequences (0-12)
PRINT_ALL Print all buffered unsolicited messages (Y/N)
CLEAR_BUF Clear unsolicited message buffer after print (Y/N)
ISSUE2-12 Items 2-12 trigger D2-D12 = See Worksheet SET A
MESG2-12 Items 2-12 messages See Worksheet SET A
USER Size of user-defined data space in registers
SET U
Not available.
