I-12 Appendix I Date Code 20010518
SEL-2020 Instruction Manual
*>>SET P 16<ENTER>
SET P 16<ENTER>SET P 16<ENTER>
SET P 16<ENTER>
Port communications settings for Port 16
Device Type (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) DEVICE = S ? M<ENTER>
M<ENTER>M<ENTER>
M<ENTER>
Communications Type (S=SEL, L=LMD, M=MODBUS, D=DNP)PROTOCOL= S ? D<ENTER>
D<ENTER>D<ENTER>
D<ENTER>
DNP Address (0-65534 or 0-FFFEh) ADDRESS = 0 ? 5<ENTER>
5<ENTER>5<ENTER>
5<ENTER>
Class for event data (0 for no event data,1,2,3)CLASS = 2 ? 0<ENTER>
0<ENTER>0<ENTER>
0<ENTER> 
Use 16 or 32-bit default variations for analog inputs (16/32)16BIT = 32 ? 16<ENTER>
16<ENTER>16<ENTER>
16<ENTER>
Select/Operate time-out interval, seconds (0.0-30.0)SO_TIMEOUT= 1.0 ? <ENTER>
<ENTER> <ENTER>
<ENTER> !
Number of data-link retries (0 for no confirmation, 1-15)DL_CONFIRM= 3 ? 0<ENTER>
0<ENTER>0<ENTER>
0<ENTER>
Minimum Delay from DCD to transmission (0-1000 msec)MIN_DELAY= 50 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Maximum Delay from DCD to transmission (0-1000 msec)MAX_DELAY= 100 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Transmission delay from RTS assertion (0-30000 milliseconds) SETTLE1=0 ? <ENTER>
<ENTER> <ENTER>
<ENTER>
Post-transmit RTS de-assertion delay (0-30000 milliseconds) SETTLE2=0 ? <ENTER>
<ENTER> <ENTER>
<ENTER>
Allow Unsolicited Reporting (Y/N) UNSOL_REP= N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Identification String
PORTID =""
? DNP port<ENTER>
DNP port<ENTER>DNP port<ENTER>
DNP port<ENTER>
Communications Settings
Baud Rate (300, 600, 1200, 2400, 4800, 9600,
19200, 38400) BAUD = 9600 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Transparent Communications Termination Sequence
PORT:16
DEVICE = M
PROTOCOL= D
ADDRESS = 5
CLASS = OFF
16BIT = 16
SO_TIMEOUT= 1.0
DL_CONFIRM= 0
MIN_DELAY= 50
MAX_DELAY= 100
SETTLE1 = 0
SETTLE2 = 0
UNSOL_REP= N
PORTID ="DNP port"
BAUD = 9600
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 16 Settings Changed
*>>
