4-6 “Job Done” Examples - (Example 1) Date Code 20010518
SEL-2020 Instruction Manual
*>>SET P F<ENTER>
SET P F<ENTER>SET P F<ENTER>
SET P F<ENTER>
Port communications settings for Port F
Port Identification String
PORTID =""
? Service port<ENTER>
Service port<ENTER>Service port<ENTER>
Service port<ENTER>
Modem Settings
Modem Control (Y/N) MODEM = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Communications Settings
Baud Rate (300, 600, 1200, 2400, 4800, 9600) BAUD = 2400 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Parity (N,O,E) PARITY = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Enable RTS/CTS handshaking (Y/N) RTS_CTS = N ? <ENTER>
<ENTER> <ENTER>
<ENTER>
Enable XON/XOFF flow control (Y/N) XON_XOFF= Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Timeout in minutes (0.0-30.0) TIMEOUT = OFF ? <ENTER>
<ENTER><ENTER>
<ENTER>
Automatic help messages enabled (Y/N) AUTO_HELP= Y ? <ENTER>
<ENTER> <ENTER>
<ENTER>
Transparent Communications Termination Sequence
First delay time (0-600 seconds) TERTIME1= 1 ?<ENTER>
?<ENTER>?<ENTER>
?<ENTER>
Termination string
TERSTRING="\004"
? <ENTER>
<ENTER><ENTER>
<ENTER>
Second delay time (0-600 seconds) TERTIME2= OFF ? <ENTER>
<ENTER><ENTER>
<ENTER>
PORT:F
PORTID ="Service port"
MODEM = N
BAUD = 2400
PARITY = N
RTS_CTS = N XON_XOFF=
TIMEOUT = OFF
AUTO_HELP= Y
TERTIME1= 1
TERSTRING="\004"
TERTIME2= OFF
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port F Setting Changed
*>>
Notes:  Enter a Port ID just for fun.
Default TERSTRING = “\004” is ASCII hexadecimal code for keystroke <CTRL-D>. Use
<CTRL-D> to end or quit transparent communication with a port.
!
Review all settings and accept the changes by typing Y<ENTER>.

!
