Date Code 20010518 “Job Done” Examples - (Example 1) 4-7
SEL-2020 Instruction Manual
3. Set Port 1 communications options using the SET P command.
You should have the following screen:
*>>
*>>*>>
*>>SET P 1<ENTER>
SET P 1<ENTER>SET P 1<ENTER>
SET P 1<ENTER>
Port communications settings for Port 1
Device Type (U=Unused, S=SEL IED, O=Other IED,
P=Printer, M=Master) DEVICE = S ? <ENTER>
<ENTER><ENTER>
<ENTER>
Auto-configure port (Y/N) CONFIG = N ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...
FID: FID=SEL-151-R412-V656rp1rqys-D941208-E2
DEVICE ID: Example 21.6 kV Line
BAUD RATE: 9600
OPERATE SUPPORT: ASCII (1 Breakers, 0 Remote Bits)
LEVEL 1 PASSWORD: OTTER
LEVEL 2 PASSWORD: TAIL
COMMANDS SUPPORTED:
B 20METER
A 20TARGET
A 20HISTORY
A 20STATUS
A 20EVENT
A 20EVENTS
Port Identification String
PORTID ="Example 21.6 kV Line"
? <ENTER>
<ENTER> <ENTER>
<ENTER>
Communications Settings
Baud Rate (300, 600, 1200, 2400, 4800, 9600,
19200) BAUD = 9600 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Number data bits (7,8) DATABIT = 8 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Stop Bits (1,2) STOPBIT = 2 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Parity (N,O,E,1,0) PARITY = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Enable RTS/CTS handshaking (Y/N) RTS_CTS = N ? <ENTER
<ENTER<ENTER
<ENTER>
>>
>
Port Timeout in minutes (0.0-30.0) TIMEOUT = OFF ? 30<ENTER>
30<ENTER>30<ENTER>
30<ENTER>
PORT:1
DEVICE = S
CONFIG = Y
PORTID ="Example 21.6 kV Line"
BAUD = 9600
DATABIT = 8 STOPBIT = 2 PARITY = N
RTS_CTS = N
TIMEOUT = 30.0
Save changes (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Port 1 Settings Changed
*>>
Notes:

Type Y<ENTER> to auto-configure the port.
Set port time-out to 30 minutes to automatically disconnect transparent communication.
!
Accept new settings by typing Y <ENTER> to save changes.

!
