Date Code 20010518 “Job Done” Examples - (Example 1) 4-9
SEL-2020 Instruction Manual
*>>SET A 1<ENTER>
SET A 1<ENTER>SET A 1<ENTER>
SET A 1<ENTER>
Automatic message settings for Port 1
Save Unsolicited Messages (Y/N) AUTOBUF = Y ? <ENTER>
<ENTER><ENTER>
<ENTER>
Port Startup String
STARTUP ="ACC\nOTTER\n2AC\nTAIL\n"
? <ENTER>
<ENTER><ENTER>
<ENTER>
Send Operate command on Logic bit transition (Y/N) SEND_OPER=N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Auto-message Settings
How many auto-message sequences (0-12) MSG_CNT = 0 ? 1<ENTER>
1<ENTER>1<ENTER>
1<ENTER>
Item 1 trigger D1
ISSUE1 = NA
? T1:00<ENTER>
T1:00<ENTER>T1:00<ENTER>
T1:00<ENTER>
Item 1 message
MESG1 = ""
? DATE
DATE DATE
DATE \
\\
\RI;1:GLOBAL:MONTH//
RI;1:GLOBAL:MONTH//RI;1:GLOBAL:MONTH//
RI;1:GLOBAL:MONTH//\
\\
\RI;1:GLOBAL:DATE//
RI;1:GLOBAL:DATE//RI;1:GLOBAL:DATE//
RI;1:GLOBAL:DATE//\
\\
\RI;1:GLOBAL:_YEAR/
RI;1:GLOBAL:_YEAR/RI;1:GLOBAL:_YEAR/
RI;1:GLOBAL:_YEAR/\
\\
\N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Item 1 response parsing method (0=IGNORE,
1=ASCII_INT, 2=ASCII_FLOAT, 3=CHAR_STRING, 4=INT_STRING)PARSE1 = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
Time delay to allow response to complete (OFF, ON)DELAY1 = ON ? <ENTER>
<ENTER><ENTER>
<ENTER>
Archive Settings
Enable use of archive data items (Y/N) ARCH_EN = N ? <ENTER>
<ENTER><ENTER>
<ENTER>
Size of user-defined data space in registers USER = 0 ? <ENTER>
<ENTER><ENTER>
<ENTER>
AUTOBUF = Y
STARTUP ="ACC\nOTTER\n2AC\nTAIL\n"
SEND_OPER=N
MSG_CNT = 1
ISSUE1 = T01:00:00.0
MESG1 = "DATE \RI;01:GLOBAL:MONTH//\RI;01:GLOBAL:DATE//\RI;01:GLOBAL:_YEAR/\
n"
PARSE1 = 0
DELAY1 = ON
ARCH_EN = N
USER = 0
Save changes (Y/N) ? Y<ENTER>
<ENTER><ENTER>
<ENTER>
Port 1 Settings Changed
*>>
Notes:

Set AUTOBUF=Yes to permit the SEL-2020 to collect and store unsolicited messages
from the relay, like summary event reports and group switch reports.
Leave automatic operate control disabled for this example.
!
Set MSG_CNT=1 so SEL-2020 prompts for one message trigger and message.
" Set ISSUE1=T01:00 to trigger MESG1 at 1:00 a.m. every day.
# Set MESG1=(as shown) to send the date command to the relay with the current date, i.e.,
DATE MM/DD/YYYY <CR>.
$ Leave DELAY1=ON so response to DATE message will not be interpreted as a response
to a following message request.
!

"
#
$
