4-10 “Job Done” Examples - (Example 1) Date Code 20010518
SEL-2020 Instruction Manual
5. Use the COPY command to copy Port 1 settings to the other ports (2, 3, 4, 5, 6, and 7) with
devices attached.
The above step results in the following screen. Port settings were not copied beyond Port 7.
If you know that all SEL IEDs are identical, you may type N<ENTER> when asked for auto-
configuration and simply enter the Port ID for each port since auto-configuration information
will be the same. Sometimes settings are lost during copying because of device
incompatibilities. Therefore, whenever you use the COPY command you should check all
settings using the SHOWSET command on each port (e.g., SHO 2).
*>>COPY 1 ALL<ENTER>
COPY 1 ALL<ENTER>COPY 1 ALL<ENTER>
COPY 1 ALL<ENTER>
Copy settings from Port 1 to Port 2 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 2 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...Done.
Port 2 Settings Changed
Copy settings from Port 1 to Port 3 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 3 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...Done.
Port 3 Settings Changed
Copy settings from Port 1 to Port 4 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 4 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...Done.
Port 4 Settings Changed
Copy settings from Port 1 to Port 5 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 5 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...Done.
Port 5 Settings Changed
Copy settings from Port 1 to Port 6 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 6 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...Done.
Port 6 Settings Changed
Copy settings from Port 1 to Port 7 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Perform auto-configuration on Port 7 (Y/N) ? Y<ENTER>
Y<ENTER>Y<ENTER>
Y<ENTER>
Attempting auto-configuration...Done.
Port 7 Settings Changed
Unable to write settings to Port 8: Internal Modem Installed
Copy settings from Port 1 to Port 9 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 10 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 11 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 12 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 13 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 14 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 15 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
Copy settings from Port 1 to Port 16 (Y/N) ? N<ENTER>
N<ENTER>N<ENTER>
N<ENTER>
*>>
Note:

Use the COPY 1 ALL as a shortcut to copy settings on Port 1 to all other ports. Port 8 is
not permitted as a destination because it has an internal modem in this example.

