Schematic CPC3
01
98455320
7 of 18
6/10/20
REFERENCE ONLY REFERENCE ONLY
98457028
PCP
1 2 3
PIOC
G
H
P7/B-8
PIOC
C
J
D
P13/B-5
P5/B-5 P6/B-8 P7/B-6
JIOC
G H
JIOC
C J D
JIOE
5 6 7
PIOE
5 6 7
P16/C-3
PLCEX
24 41 23 40 22 39 21 38
STROKE COUNTER
41 3
-
+
S
OIL PRESSURE
98462245
21 3
-
+
S
P
HORN PUSH
BUTTON
NO
PUSH BUTTON
PLC - 98391422
EX24 - IN08
STROKE COUNTER
EX41 - IN09
OIL PRESSURE
EX23 - IN10
HORN PB
EX40 - IN11
REMOTE ENABLED
EX22 - IN12 EX39 - IN13 EX21 - IN14 EX38 - IN15
PLCEX:40-PPRS:1
WH 0.8mm²
P18/B-7
PLCEX:24-JIOE:5
WH 0.8mm²
PLCEX:41-JIOE:6
WH 0.8mm²
PLCEX:23-JIOE:7
WH 0.8mm²
PIOE:6-PCP:2
BU 0.8mm²
PIOE:5-PIOC:C
WH 0.8mm²
PIOE:7-PIOC:G
WH 0.8mm²
PIOC:D-SP22
RD 0.8mm²
P16/A-4
PIOC:H-SP22
RD 0.8mm²
P16/A-4
PCP:1-SP22
BN 0.8mm²
P16/A-3
PIOC:J-SP23
GY 0.8mm²
P16/A-3
PCP:3-SP23
BU 0.8mm²
P16/A-3
