Schwing CPC III - Page 40

DATE
SHEET NUMBER
REV.
SIZE
DRAWING NUMBER
B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A
A
B
B
C
C
Schematic CPC3
01
98455320
8 of 18
6/10/20
OUTPUTS 00 - 07 ARE POWERED BY VBB0
OPTIONAL
REFERENCE ONLY
PRC
Z
N
a P
P17/C-8
JRC
Z N a P
PDP1
2 3
PDP1
1 4
PDP2
2 3
PDP2
1 4
PLCST
18 17 16 15 14 13 12 11
CONCRETE
PUMP DUMP
AGITATOR OR
ACCUMULATOR
DUMP
JDP1
1
23
4
DT Diode Pack
JDP2
1
23
4
DT Diode Pack
PLC - 98391422
18 - OUT00
CONCRETE PUMP DUMP
17 - OUT01
AGITATOR DUMP
16 - OUT02 15 - OUT03 14 - OUT04 13 - OUT05 12 - OUT06 11 - OUT07
PDP2:3-PLCST:18
WH 0.8mm²
PDP1:3-PLCST:17
WH 0.8mm²
PDP1:4-PRC:N
WH 0.8mm²
PDP2:4-PRC:Z
WH 0.8mm²
PDM10:F-PRC:P
GY 0.8mm²
P3/C-3
PDM10:E-PRC:a
GY 0.8mm²
P3/C-3
PMS:3-PDP1:2
WH 0.8mm²
P18/B-5
PDP1:1-PLCST:22
WH 0.8mm²
P5/B-4
PDP2:1-SP16
WH 0.8mm²
P13/B-2
PMS:4-PDP2:2
WH 0.8mm²
P18/B-5
