Schwing CPC III - Page 47

DATE
SHEET NUMBER
REV.
SIZE
DRAWING NUMBER
B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A
A
B
B
C
C
Schematic CPC3
01
98455320
15 of 18
6/10/20
98461655
USED FOR PROGRAMMING ONLY
JUMPER PLUG REQUIRED
FOR NORMAL OPERATION
SP7 SP8
JRADA
2 3 4 5
PPPT
C
D
L
B
M
F
A
PDIS
5-GRY
4-BLK
2-WHT
3-BLU
JPPT
C D L B M F A
PRADA
2-WHT
3-BLU
4-BLK
5-GRY
PLCST
51 49 31 48 30 50 25 43 26 44 27 45 28 46 29 47
120 Ohm
120 Ohm
RADIO RECEIVER
12vDC
GND
CAN H
CAN L
86
120 Ohm
PUMP DISPLAY
98395784
12vDC
GND
CAN H
CAN L
PLC - 98391422
26 - CAN4_L 27 - CAN3_L 28 - CAN2_L 29 - CAN1_L 44 - CAN4_H 45 - CAN3_H 46 - CAN2_H 47 - CAN1_H 25 - RxD 30 - USB_P 31 - USB_5V 43 - TxD 48 - USB_N 49 - USB_GND 50 - TEST 51 - vREF OUT
PLCST:47-SP7
YL 0.8mm²
PLCST:29-SP8
GN 0.8mm²
PLCST:43-PPPT:C
WH 0.8mm²
PLCST:25-PPPT:D
WH 0.8mm²
PLCST:50-PPPT:L
WH 0.8mm²
PPPT:A-SP13
RD 0.8mm²
P14/B-8
PDM3:A-PPPT:B
GY 0.8mm²
P3/C-7
PPPT:F-SP8
GN 0.8mm²
P15/B-7
PPPT:M-SP7
YL 0.8mm²
P15/B-8
JPPT:B-L
WH 0.8mm²
PDIS:5-SP8
GY 0.8mm²
PDIS:4-SP7
BK 0.8mm²
PDM3:D-PDIS:3
BU 0.8mm²
P3/C-6
PDM3:F-PRADA:3
BU 0.8mm²
P3/C-6
PDM12:G-PRADA:2
WH 0.8mm²
P3/A-3
P16/C-2
JIOE:3-SP7
YL 0.8mm²
PPPT:M-SP7
YL 0.8mm²
P15/B-3
JIOE:4-SP8
GN 0.8mm²
P16/C-2
PPPT:F-SP8
GN 0.8mm²
P15/B-3
PLCST:45-PRADA:4
BK 0.8mm²
PLCST:27-PRADA:5
GY 0.8mm²
PDM1:D-PDIS:2
WH 0.8mm²
P3/A-8
