Schwing CPC III - Page 48

DATE
SHEET NUMBER
REV.
SIZE
DRAWING NUMBER
B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A
A
B
B
C
C
Schematic CPC3
01
98455320
16 of 18
6/10/20
IGNITION CONTROLLED
REFERENCE ONLY
98457028
SP23SP22
PKP
4 3 2 1
SP27
SP28 SP29 SP30SP31
PCAN1
2 1
SP34
SP35
PPC
A
B
C
D
E
F
G
H
J
JPC
A B C D E F G H J
JIOE
5
SEE PAGE 7 ZONE 8-C
6
SEE PAGE 7 ZONE 7-C
7
SEE PAGE 7 ZONE 6-C
8
SEE PAGE 13 ZONE 4-B
9
SEE PAGE 13 ZONE 5-B
10
SEE PAGE 6 ZONE 7-C
11
SEE PAGE 6 ZONE 8-C
12
SEE PAGE 5 ZONE 5-B
1 2 3 4
PIOE
5
SEE PAGE 7 ZONE 8-B
6
SEE PAGE 7 ZONE 7-B
7
SEE PAGE 7 ZONE 6-B
8
SEE PAGE 13 ZONE 4-B
9
SEE PAGE 13 ZONE 5-B
10
SEE PAGE 6 ZONE 7-B
11
SEE PAGE 6 ZONE 8-B
12
SEE PAGE 5 ZONE 5-B
1 2 3 4
P5/B-5 P6/B-8 P7/B-8
P13/B-5
REAR KEYPAD
98455321
CAN L
CAN H
GND
12vDC
80a
+
-
OIL
COOLER
+
-
M
ELECTRIC
VIBRATOR
+
-
M
BOOM HORN
1
2
CAN1
120 Ohm
PDM9:D-PPC:H
RD 1.3mm²
P3/A-5
PDM12:H-PPC:F
RD 2.0mm²
P3/A-3
PDM4:H-PPC:G
RD 1.3mm²
P3/A-6
PPC:A-GND:T3
BK 3.2mm²
P3/C-4
PPC:J-GND:T3
BK 3.2mm²
P3/C-4
PPC:D-12v:T1
RD 2.0mm²
P3/C-5
PPC:B-12v:T2
RD 2.0mm²
P3/C-5
PPC:C-12v:T2
RD 2.0mm²
P3/C-5
PPC:E-12v:T1
RD 2.0mm²
P3/C-5
JIOE:3-SP7
YL 0.8mm²
P15/B-8
JIOE:4-SP8
GN 0.8mm²
P15/B-7
PDM1:G-JIOE:1
RD 0.8mm²
P3/A-7
PDM10:A-JIOE:2
GY 0.8mm²
P3/C-3
PIOE:1-SP22
RD 1.3mm²
PIOE:2-SP23
GY 1.3mm²
PKP:3-SP34
YL 0.8mm²
PKP:4-SP35
GN 0.8mm²
P7/B-8
PIOC:D-SP22
RD 0.8mm²
PIOC:H-SP22
RD 0.8mm²
P7/B-6
PCP:1-SP22
BN 0.8mm²
P7/B-7
PIOC:J-SP23
GY 0.8mm²
P7/B-8
PCP:3-SP23
BU 0.8mm²
P7/B-7P6/B-8
PIOC:L-SP22
RD 0.8mm²
PIOC:A-SP23
GY 0.8mm²
P13/B-5
PKP:2-SP23
GY 0.8mm²
PKP:1-SP22
RD 0.8mm²
PCAN1:1-SP34
YL 0.8mm²
PIOE:3-SP34
YL 0.8mm²
PCAN1:2-SP35
GN 0.8mm²
PIOE:4-SP35
GN 0.8mm²
