Rev 37 Operator’s Manual OM-610-1002-1
page 50 SECTION 6 MAINTENANCE PDS-2010
Parameter Description (Setup)
Parameter Description West Factory Default
FiLt Input Filter Time constant 2.0 sec.
OFFS Process Variable Offset 0
PPLJ Primary (Heat) power *read only
Pb_P Proportional Band 10
ArST Automatic Reset (Integral Time) 5
rAtE Rate (Derivative Time) 1.15
biAS Manual Reset (Bias) 25
SPuL Setpoint Upper Limit Max. Range
SPLL Setpoint Lower Limit Min. Range
OPuL Output Power Limit 100%
Ct 1 Output 1 Cycle Time 32 sec.
bAL 1 Band Alarm 1 value 5
PhA 1 High Alarm 1 value Max. Range
PLA 1 Low Alarm 1 value Min. Range
AHY 1 Alarm 1 Hysteresis 1
PhA 2 High Alarm 2 value Max. Range
AHY 2 Alarm 2 Hysteresis 1
APt Auto Pre-tune diSA
PoEn Auto/manual Control selection diSA
SPr Setpoint ramping diSA
rP SP Ramp Rate value Off
SP Setpoint Min. Range
Sloc Setup Lock Code 10
NOTE: The Vacuum controller set point is set for an operating pressure of 15 units above base pressure
(PLA1), as established during the factory test procedure. You can adjust it as warranted for a specific coating
application and to accommodate changes in system base pressure.
