OM-610-1002-1 Operator’s Manual Rev 37
PDS-2010 SECTION 6 MAINTENANCE page 49
Parameter Description (Configuration)
Parameter Description West Factory Default
inPt Input Type and Range JC
ruL Scale Range Upper Limit 1200
rLL Scale Range Lower Limit -200
dPoS Decimal point position 1
CtyP Control Type SnGL
CtrL Primary Output Control Action REv (reverse acting)
ALA 1 Alarm 1 Type P_Hi
PhA 1 Process High Alarm 1 value* Range Max.
PLA 1 Process Low Alarm 1 value* Range Min.
bAL 1 Band Alarm 1 value* 5
AHY 1 Alarm 1 Hysteresis * 1
ALA 2 Alarm 2 Type P_Lo
PhA 2 Process High Alarm 2 value* Range Max.
PLA 2 Process Low Alarm 2 value* Range Min.
bAL 2 Band Alarm 2 value* 5
AHY 2 Alarm 2 Hysteresis* 1
LAEn Loop Alarm Enable diSA
Inhi Alarm Inhibit nonE
USE 1 Output 1 Usage Pri
USE 3 Output 3 Usage A1_d
diSP Display Strategy 1
Cloc Configuration Mode Lock Code 20
