SDLG WP6 User Manual

Service Manual for WP6 Diesel Engine
19
Table 2-6
Cylinder 1
Cylinder 2
Cylinder 3
Cylinder 4
Cylinder 5
Cylinder 5
Cylinder 1 in
compression stroke
Intake and
exhaust
valve
Intake
valve
Exhaust
valve
Intake
valve
Exhaust
valve
Cannot be
adjusted
Cylinder 6 in
compression stroke
Cannot be
adjusted
Exhaust
valve
Intake
valve
Exhaust
valve
Intake
valve
Intake and
exhaust
valve
 Replace fuel filter element
Follow the steps below to replace fuel filter element:
 Remove the old fuel filter element; if the water collector that installed on coarse filter can be
reused, please the take collector down.
 Lubricate the seal.
 Screw on the filter with hand until the seal touched the port.
 Continue to tighten the filter with hand until it is firmly installed (About 3/4 circle).
 Drain all air in fuel system out.
 Perform leakage test.
Fuel filter
Fig. 2-14 Fuel filter
 Check intake system
Check whether intake rubber hose is aged and cracked, whether the circumferential band is loose.
