Service Manual for WP6 Diesel Engine
56
342 Disassembly, Inspection, Maintenance and Assembly of Piston-Rod
Assembly
3421 Exploded View of Piston-Rod Assembly
Piston-rod assembly
Piston-rod assembly
Crankshaft
Engine block module
Fig. 3-26 Schematic diagram of piston-rod assembly
Connecting rod body
Piston pin
Piston pin circlip
Elastic locating pin
Connecting rod cap
Connecting rod bolt
First compression ring
Second compression ring
Oil ring
Piston
Connecting rod
sleeve
Connecting rod bearing
top half shell
Connecting rod bearing
bottom half shell
Fig. 3-27 Exploded view of piston-rod assembly
