Service Manual for WP6 Diesel Engine
46
Assembling:
(1) Knock-in locating pins, as shown in Fig. 3-15;
Fig. 3-15 Knock-in locating pins
(2) Apply sealant on the fitting surface of engine front cover, make sure the sealant is evenly
distributed and no discontinuity.
Fig. 3-16 Sealant application of engine front cover
(3) Place engine front cover and align pins and pin holes, knock the cover edge gently with nylon
rod, so that the cover and engine block can joint closely.
Fig. 3-17 Knock engine front cover
(4) Place the bolts with gaskets to their corresponding holes and tighten them with pneumatic
impact wrench and open-end wrench.
