Service Manual for WP6 Diesel Engine
54
3382 Steps to Disassemble Front and Rear Oil Seals
(1) Remove engine front cover (refer to section 333);
(2) Remove front oil seal;
(3) Remove rear oil seal (key point 1);
3383 Inspection and Maintenance of Front and Rear Oil Seals
Key point 1:
Inspection:
Oil seals and seal rings should be checked before assembling, make sure there is no damage. Check
whether rear oil seal cover is clean and whether its finished surface is free of obvious scratch.
Assembling:
Apply sealant on the rear oil seal outer ring first, and then press-in the seal slowly with dedicated
tool. NOTICE: Do not damage the seal during assembling, and seal outer ring should be parallel
and level to oil seal cap plane.
3384 Steps to Assemble Front and Rear Oil Seals
Assembling steps are contrary to disassembling ones.
