Service Manual for WP6 Diesel Engine
77
(4) Check air filter, clean it timely if there is too much dust accumulated in the filter.
3644 Steps to Assemble Turbocharger System
(1) Loose-fit one end of the preassembled turbocharger oil inlet pipe to engine block main oil port.
Pay attention to adjust the poison of the pipe, so that it can be easily connected to turbocharger.
(2) Install turbocharger gasket on exhaust adapter flange.
(3) Install turbocharger oil return pipe and studs on turbocharger assembly, apply 0# molybdenum
disulfide and clean lubricating oil on the studs. Tighten oil return pipe fixing bolts to 22~29Nm.
(4) Place a gasket on exhaust adapter flange and fix them on turbocharger assembly, loose-fit
2-type all-metal hexagon lock nuts and tighten them.
(5) Pour proper amount of clean lubricating oil into turbocharger oil inlet port, and clean up the
overflowed oil.
(6) Connect oil inlet pipe to turbocharger with a gasket, fix them with hexagon bolts and
self-locking gaskets, tighten the bolts to 22~29Nm. Rotate supercharger impeller and it should
be flexible and free of resistance.
(7) Install turbocharger oil return hose and hose clamps, tighten the clamps. Note that the direction
of two clamps should be uniform, straighten out the house.
(8) Install gaskets and studs, connect the muffle.
(9) All gaskets are disposable and should be replaced once removed.
