7 Battery charge alternator 8 Starter batteries
Figure 2.1 (continued): General description of the generating set
9 Coolant filter 12 External fuel supply combined tap (optional)
10 Filling with fuel 13 Circuit breaker
11 Oil filters 14 Interchangeable fuel pre-filters
Figure 2.1 (continued) : General description of the generating set
9
10
11
12
14
13
7
8
15/285
