SDMO R 340 U - Facility Power Outlet

Connection of generating sets to client terminal boards
Reinsert the shunts of terminals 45 and 46 after having disconnected the current transformer from the
junction box.
Important
6.3.5.4. Facility power outlet
The facility power outlet (if fitted) provides the emergency supply to the generating set from an external electrical source. It enables
the different units (preheating, desk, etc.) to be powered without using their batteries.
7
44
45
42
43
40
41
38
39
36
37
34
35
32
33
30
31
28
29
46
47
48
Xcbc3
7
44
45
42
43
40
41
38
39
36
37
34
35
32
33
30
31
28
29
46
47
48
Xcbc3
Junction box
Remove the shunts at
terminals 45-48 and 46-47
83/285
