6.2.3 Switching off
Open the circuit breaker
manually OR by selecting menu 12 "CONTROL LOAD"
The following display will disappear (supply stopped)
Press the STOP button
The following screen is displayed and the generating set will stop
OFF
IN PROGRESS
24/08/2005 13:12
Switch TELYS off by turning the key to "OFF" (without forcing it to the "OFF" position).
6.2.4 Alarms and faults
6.2.4.1. Viewing alarms and faults
Alarms and faults are displayed as follows:
Alarms
All alarms will cause:
the yellow LED to flash "General alarm".
In conjunction with this LED:
a flashing pictogram appears on the LCD screen
representing the circuit affected by the alarm and the
associated indicator, if present
(example)
message on graphic display (example)
FAULT
ALARM
Low Fuel Level
25/12/05 15:30
OK=HELP
Faults
All faults will cause:
the generating set to stop: immediate or gradual stop (coolant temperature and overload or short circuit)
the red LED to flash "General fault".
