9.4. Appendix D - List of John Deere - Volvo and Perkins fault codes
SPN CID SID PID PPID FMI
John Deere
Volvo
Perkins
Description Comment
28 Throttle #3 Position
3 Throttle Voltage high, short to V+ Short to V+
4 Throttle Voltage low, short to V- Short to V-
29 Throttle #2 Position
3 Throttle Voltage high, short to V+ Short to V+
4 Throttle Voltage low, short to V- Short to V-
14 Throttle voltage out of range
84 Vehicle speed
2 Vehicle invalid or missing
Not possible with Genset
application
31 Vehicle speed mismatch
91 91 91 132 Accelerator pedal position
FMI not determined for all
VOLVO’s
3 Throttle Voltage high, short to V+
Not possible with genset
application, codes declared
by the CAN J1587 for
VOLVO.
4 Throttle Voltage low, short to V-
7 Throttle calibration invalid
8 PWM throttle abnormal pulse width
9 Throttle invalid (CAN value)
10 Throttle voltage out of range low
13 Throttle calibration aborted
14 Throttle voltage out of range
94 94 Fuel rail pressure sensor
1 Fuel supply pressure extremely low
3 Fuel rail pressure input voltage high Short to V+
4 Fuel rail pressure input voltage low Short to V-
5 Fuel rail pressure sensor open circuit
10 Fuel rail pressure lost detected
13 Fuel rail pressure higher than expected
16 Fuel supply pressure moderately high
17 Fuel rail pressure not developed
18 Fuel supply pressure moderately low
97 97 Water in fuel sensor
0 Water in fuel continuously detected
3 Water in fuel input voltage high Short to V+
4 Water in fuel input voltage low Short to V-
16 Water in fuel detected
31 Water in fuel detected
98 98 Oil level sensor
1 Oil level value below normal
3 Oil level sensor input voltage high Short to V+
4 Oil level sensor input voltage low Short to V-
5 Oil level sensor open circuit
