6.3.3 Description of the Man Machine Interface (IHM/MMI)
6.3.3.1. The Man Machine Interface
Display
The display has the following specifications:
 7-inch colour TFT display, 16/9, 65536 colours
 dimensions: 154 mm x 86 mm
 neon backlighting
 480 x 234 resolution
 touch panel (8 columns x 8 rows).
Signalling control
keys
Operating buttons of the
generating set
Backlit display with touch-sensitive keypad
Alphanumeric keypad
Navigation keys
M.M.I. operation LED
(flashing)
