SPN CID SID PID PPID FMI
John Deere
Volvo
Perkins
Description Comment
653 3 3 653 Cylinder #3 injector status
0 Injector outside the specifications
Recalibration of the injectors
required
1 Injector outside the specifications
Recalibration of the injectors
required
2 Short circuit high side to B+
3
Short circuit high side to low side or low
side to B+
4 Short circuit high or low side to ground
5 Cylinder #3 circuit open
6 Cylinder #3 circuit shorted
7
Cylinder #3 balancing error/mechanical
failure
11
Cylinder #3 unknown error/mechanical
failure
654 4 4 654 Cylinder #4 injector status
0 Injector outside the specifications
Recalibration of the injectors
required
1 Injector outside the specifications
Recalibration of the injectors
required
2 Short circuit high side to B+
3
Short circuit high side to low side or low
side to B+
4 Short circuit high or low side to ground
5 Cylinder #4 circuit open
6 Cylinder #4 circuit shorted
7
Cylinder #4 balancing error/mechanical
failure
11
Cylinder #4 unknown error/mechanical
failure
655 5 5 655 Cylinder #5 injector status
0 Injector outside the specifications
Recalibration of the injectors
required
1 Injector outside the specifications
Recalibration of the injectors
required
2 Short circuit high side to B+
3
Short circuit high side to low side or low
side to B+
4 Short circuit high or low side to ground
5 Cylinder #5 circuit open
6 Cylinder #5 circuit shorted
7
Cylinder #5 balancing error/mechanical
failure
11
Cylinder #5 unknown error/mechanical
failure
