2.3. Identifying sets
Generating sets and their components are identified by means of identification plates.
The precise rules for identifying each major component (engine, alternator, etc.) are set out in each manufacturer's documentation
contained in the appendices of this manual.
1 - Generating set
2 - Manufacturer name
3 - Model
4 - Serial number
5 - Year of manufacture
6 - Rated output (kVA and kW) according to the ISO
8528-1 standard
PRP: main power
ESP: emergency power
7 - Rated power factor
8 - Maximum altitude of the site above sea level (m)
for the rated power
9 - Maximum ambient temperature for the rated
power (°C)
10 - Rated frequency (Hz)
11 - Generating set rotation speed (RPM)
12- Rated voltage (V)
13 - Rated current (A)
14 - Weight (kg)
15 - CE marking
16 - Non CE standard marking
(e.g.: GOSSTANDART)
17 - Sound pressure
18 - Sound power
Figure 10 : Example of a generating set identification plate
