9.2.
Neutral system
Turn the switch to the desired neutral system.
Select the neutral system with th
e generating set switched off.
Important
9.3.
Fuel supply valve
The 3-way valve is used to se
lect between the gener
ating s
et fuel tank and an external fuel suppl
y.
Valve in vertical position (no. 1): generati
ng set suppl
ied by the daily service tank.
Valve in horizontal positio
n (no. 2): generating set supplied b
y the external tank.
EDF
TT
Ф
2
1
91/242
92
94
