4.2.2.5. Earthing the generating set
Risk of electric shock.
Before use, the generating set must always be earthed. Protection against electric shocks is only effective
once the earthing connection has been made.
Disconnect the battery leads, starting with the negative lead (-), or use the battery isolating switch before
carrying out any operations on the generating set.
DANGER
1. Open the door to the power section (no.1) then the access
door to the cable router flap and to the connection terminal
box (no.2).
2. Connect the earth cable (supplied) to the terminal (rep.3)
on the generating set located on the connection terminal
box.
3
1
2
