SDMO R33C3 - Figure 8: General Description of the Generating Set (Continuation)

Figure 8 : General description of the generating set (Continuation)
1 Protective grille 4 Alternator
2 Battery isolating switch 5
External fuel supply combined tap
(optional)
3 Starter battery 6 Charging alternator
3
1
2
4
6
5
16/242
