SEAWARD PRIMETEST SERIES USER MANUAL
TESTED. TRUSTED… WORLD WIDE Page 53 of 77
From the Main Menu select Upload by using the keyboard arrow keys or selecting key
number 7.
In the Upload data into PrimeTest field select List Configuration Data, using the keyboard arrow
keys to select from the dropdown menu.
Follow a similar method described in the Uploading from PATGuard 3 (AUS/NZ) to a PrimeTest Elite+ or
PrimeTest Pro
The PrimeTest will begin the upload and in the PrimeTest Configuration Upload message display
the field name and number of each uploaded, for example;
Press OK to accept the upload. This uploaded data can then be used from the dropdown selections when
setting up / using your PrimeTest Elite+ or PrimeTest Pro.
11 Performing an Electrical Safety Test – Auto Mode
The Portable Appliance Testing window can be selected from the Home Screen by selecting
(F1).
