BGX501-742-R01, APEX 100 User Manual
Page 67 of 104
Select either Active Energy-Total or
Active Energy-Fund(amental)
Active Energy-Total selected for LED1
Select either LED1 or LED2 for configuration
Metro LED2 selected
Select either Reactive Energy or
Apparent Energy.
Reactive Energy selected for Metro LED2
Confirmation screen will be displayed
This screen allows you to set the display timeout
settings.
