ThefusesarelocatedattherearoftheACunitinsidethebase.
① Turnthemainswitchoffandunplugthepowercordfromtheoutlet.
②Removethefrontfloorofthebase.Thefrontfloorismorethan80cmwide.Atleast2people
areneededtoperformthisoperationsafelyandreliably.Removethe10trussscrewsholdingthe
frontfloorinplace.
TRUSSSCREW(5),black
M4×8
TRUSSSCREW(5),black
M4×8
FLOORFRONT
PHOTO18.5a
③ Thereisawireconnectionontheinsideofthefrontfloor.Lifttherearofthefrontfloor(the
sideoppositetheACunit)and,holdingitinatiltedposition,unplugthesingleconnector.
Unplugthesingleconnector.
PHOTO18.5b
