121
12 −1 ADJUSTINGANDREPLACINGTHESTEERINGVR
ThevariableresistorthatdetectssteeringinthedirectionalcontrolsiscalledtheX-axissteering
VR.ThereareVRunitslocatedonthetopandbottomofthebaseinterior,justinsidethefront
lid.ThesteeringVRunitistheoneontop.
Inthismachine,theVRwillnotbedamagedaslongasitsaxlerotateswithinitsrangeof
motionwhenthesteeringunitisturnedallthewaytotheleftandright.SecuretheVRsothatits
axlepointsintheindicateddirectionandthegearisproperlyengagedwhenthesteeringunitis
inthestraightposition.
Thefollowingtoolsandinstrumentsarerequiredtoperformtheseoperations.
-M4-sizePhillipsscrewdriver
-1.5mmdiameterhexagonalscrewdriverorwrench
-11-12mmdiameterspanner
-Nippers
-Cutters
-Solderingiron
-Industrialdryer
Turnoffthepower.
Removethe6trussscrewsholdingthefrontlidofthebaseinplaceandthenremovethelid.
 FRONTLID 
 TRUSSSCREW(6),black 
 M4×8
PHOTO12.1a
ADJUSTMENTPROCEDURE
