Sega AV F-ZERO AX User Manual

− 116 −
11 −２ REPLACINGTHEMICROSWITCHES
Movementinthesteeringunit'spaddleleversisdetectedby2microswitchesonthebottomof
theinteriorofthesteeringcover.Followthestepslistedbelowtoreplaceoradjusttheposition
oftheseswitches.
Notethateachofthe2microswitchesonthebottomofthesteeringunitislinkedtothepaddle
ontheOPPOSITEsideinthe"PADDLELEFT/RIGHT"testontheInputTestscreen;thatis,
themicroswitchontherightcontrolsthe"PADDLELEFT"value,andvice-versa.Checkto
makesuretheswitchbeingreplacedoradjustedisthecorrectone.
Thefollowingtoolsandinstrumentsarerequiredforthefollowingoperations:
-3mmdiameterhexagonalscrewdriverorwrench
-M4-sizePhillipsscrewdriver
-M3-sizePhillipsscrewdriver
-Nippers
-Cutters
-Solderingiron
-Industrialdryer
① Performsteps1through7foradjustingtheY-axisVRtoremovethefrontsteeringcoverand
detachtherearsteeringcover(see11-1).
② Loosenthe2screwssecuringtheSWADJUSTplateonwhichthemicroswitchtobeadjustedin
installed,andthenmovetheSWADJUSTplatetoadjustit.Donotloosenthescrewsonthe
sidethemicroswitchisinstalledon.
PHOTO11.2a
ADJUSTMENTPROCEDURE
SCREW(2)
M3×6,w/flat&springwashers
PADDLELEFTSIDESWITCH
PADDLERIGHTSIDESWITCH
