Sega AV F-ZERO AX User Manual

− 133 −
14. COIN SELECTOR
FIG.14b
FIG.14a
COININSERTIONTEST
Onceeverymonth,whenperforming
theCoinSWTest,simultaneously
checkthefollowing:
FIG.14c
GATE
CRADLE
●●
●●
● Removeandcleansmearsbyusing
asoftclothdippedinwateror
dilutedchemicaldetergentandthen
squeezeddry.
●●
●●
● Neverapplymachineoil,etc.tothe
CoinSelector.
●●
●●
●AftercleaningtheCoinSelector,
insertaregularcoininthenormal
workingstatusandensurethatthe
Selectorcorrectlyfunctions.
IfthecoinisnotrejectedwhentheREJECTbuttonispressed,openthecoinchutedoorand
opentheselectorgate.Afterremovingthejammedcoin,putanormalcoininandchecktosee
thattheselectorcorrectlyfunctions.
Insertacoinwhile
keepingtheRejectButton
presseddownandcheckif
itisrejected.
COINMETER
①TurnthepowerforthemachineOFF.Openthe
coinchutedoor.
② Removethecoinselectorfromthecoinchutedoor.
③ Openthegateanddustoffbyusingasoftbrush
(madeofwool,etc.).
④ Removeandcleansmearsbyusingasoftcloth
dippedinwaterordilutedchemicaldetergentand
thensqueezeddry.
⑤ RemovetheCRADLE.
Whenremovingtheretainingring
(Ering),beverycarefulsoasnottobendthe
rotaryshaft.
⑥ Removestainfromtherotaryshaftandshaft
receivingportionsbywipingoffwithasoftcloth,
etc.
⑦ Afterwipingoffasper⑥above,furtherapplya
drycloth,etc.tocausethecoinselectortodry
completely.
□ DoestheCoinMetercountsatisfactorily?
□DoesthecoindropintotheCashboxcorrectly?
□ Isthecoinrejectedwheninsertedwhilekeepingthe
RejectButtonpresseddown?
Thecoinselectorshouldbecleanedonceevery3months.
Whencleaning,followtheprocedurebelow:
HANDLINGTHECOINJAM
CLEANINGTHECOINSELECTOR
