Sega AV F-ZERO AX User Manual

− 160 −
① Turnoffthepower
② Removetherightfloorfromtheside
ofthebasenexttothecoinchute
tower.Tounlatchthefloor,remove
the2trussscrews.
19 −１ REMOVINGTHEGD-ROMDRIVE
Unlock.
FLOORR
PHOTO19.1a
③ Unfastenthe2cordclampssecuring
thewiresinsidethebase.
GDCABLE
CORDCLAMP
PHOTO19.1b
TRUSSSCREW(2)
M4×8,chrome
