− 161 −
PHOTO19.1e
⑥ Removethe3screwsandthenremove
theGD-ROMdrive.
 GDCABLECONNECTOR 
 GD-ROMDRIVE 
 TRIFORCE 
④ UnplugtheGDcableconnectorfrom
theGD-ROMdrive.
PHOTO19.1c
 ACCABLECONNECTOR 
 JSTNH6P
 GD-ROMDRIVE 
⑤ Unplugthepowercableconnector
fromtheGD-ROMdrive.
PHOTO19.1d
 SCREW(3)         
 M4×16,w/flat&springwashers
