19 −３ COMPOSITIONOFTHEGAMEBOARD
Withthekeychipinstalled,theTRIFORCEboardbecomesaproprietary
gameboardforthisproduct.
KEYCHIP
TRFDIMMMEDIABD
842-00FD0000
TRFMAINBDUSA(842-00A0000U)<USA>
TRFMAINBDEXP(842-00A0000E)<OTHERS>
DIPSW
ASSYTRFFZRUSA（842-02DD511U）: USA
ASSYTRFFZREXP（842-02DD511E）: OTHERS
ASSYTRFFZRASIA（842-04DD511E）: ASIA
FIG.19.3b
FIG.19.3a
UsethisproductwiththeDIPSWsettingsshowninthefigurebelow.
DIPSWSETTING
