Sega AV F-ZERO AX User Manual

−72−
(FRONT)
(REAR)
(WOOFER)
(TEST)
(SERVICE)
(DEMAG.)
① VOLUMECONTROL: Adjuststhevolumeofthespeakersontheleftandrightsides
ofthemonitor.
② VOLUMECONTROL: Adjuststhevolumeofthespeakersontheleftandrightof
theseatheadrest.
③WOOFERCONTROL: Adjuststhevolumeofthewooferoutputinsidethebase.
④ TESTBUTTON: Forthehandlingofthetestbutton,refertothefollowing
pages.
⑤ SERVICEBUTTON: Givescreditswithoutregisteringonthecoinmeter.
⑥ DEMAGNETIZERSWITCH: Eliminatestheon-screencolorunevennessdueto
magnetizationofCRT.FirstusethisSWbeforeperforming
themonitor'scoloradjustment.
10 − 1 SWITCHUNITANDCOINMETER
Nevertouchplacesotherthanthosespecified.Touchingplacesnot
specifiedcancauseelectricshockandshortcircuitaccidents.
● Adjustthesoundtotheoptimumvolume,takingintoconsiderationthe
environmentalrequirementsoftheinstallationlocation.
● RemovingtheCoinMetercircuitryrendersthegameinoperable.
FIG.10.1a SWITCHUNIT
Openthecoinchutedoor,andtheswitchunitshown
willappear.
ThefunctioningofeachSWisasfollows:
SWITCHUNIT
①
⑥
⑤④
③②
